Color sorters used in food and processing industry. They are essential for maximum quality selection of bulk raw materials. For example, color sorters have place in finish of preparing process at flour mills. Grain passes through the machine once and grain is sorted to 99,9% purity. Besides grain, color sorters used for sorting of other products like nuts, leguminous crops, oilseeds, grass seeds, dried fruits and berries.
Raw materials could be sesame, wheat, oats, buckwheat, sunflower, tea, beans etc. In any agricultural culture, the use of high-quality seed material is of particular importance. Seed cleaning is very important stage. Color sorter use let to to supply the market with premium products complying with current quality standards.
Technical Parameter
| Model | 6SXM-320JM5 |
| Output(T/h) | 1.0~2.0 |
| Carryover Rate(Bad:Good) | >20:1 |
| Sorting Accuracy(%) | ≥99 |
| Voltage (V/Hz) | 220V 50HZ |
| Power Supply(Kw) | ≤3.0 |
| Pressure(Mpa) | 0.4-0.6 |
| Weight(Kg) | 1360(±5%) |
| Diamension(mm) | 2330*1630*2030 |
Sorting Material
Description of work:
Raw product go into the receiving hopper 7. Vibrating feeder 1 feeds material to feeding tray evenly. Product through feeding tray goes to inspection area for color cameras 3 and 10. The Product illuminated by powerful LED backlight 4. And the product is scanned from both sides by high-speed cameras for a defect according to the criteria set by the operator through the control panel 2. Good finished product continues to move into chamber for clean product 6. If the product is identified as dirt, then it move to the channel for waste fraction 5 by air ejector 11.
